A built-in piezoelectric type online dynamic balance actuator which includes two structurally identical left and right piezoelectric drive adjustment mechanisms at two sides of a housing. The piezoelectric drive adjustment mechanism includes a shaft having one end supported inside a housing chamber by bearing, a middle portion connected to an end cover by bearing, and the other end supported on bearing housing by bearing, a weight mass coupled to the shaft and positioned inside a tightening sleeve with one side connected to the bearing housing and another side connected to the end cover and the housing, and a stator fixedly connected to one side of the end cover, a mover pressed against a surface of the stator through a disk. Through a control center, the mass weights of the left and right piezoelectric drive adjustment mechanisms are fixed to a preset angle. As the main shaft rotates at a high speed, the two weight masses generate centrifugal force which combine to a balance vector to cancel the imbalance vector of the main shaft, improve the mass distribution of the main shaft and better fit the online dynamic balance requirements.

Claims data not available
