METHOD AND A DEVICE FOR PREPARING SHEET MATERIAL TO BE USED FOR A PAGE OF A BOOK, A PRINTING PAPER SHEET FOR A PAGE OF A BOOK, AND A BOOK
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jul 5, 2012
app pub date -
Sep 10, 2010
filing date -
Sep 11, 2009
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A method for preparing sheet material (10, 80) to be used for a page of a book comprises forming—in essentially an even sheet material (10, 80) adapted for use in a modern printing method in which the sheet material (10, 80) runs through a set of cylinders and/or rolls—at least one hinge area (18), extending for a distance (L, K+L) from the edge (14) of the sheet material (10, 80) that is intended as the binding edge of a book, towards the center of the sheet material (10, 80), by making, in the hinge area (18) of the sheet material (10, 80), several weakenings (11) that are parallel to the edge (14), are adjacent to each other and are located at increasing distances with respect to each other from the edge of the sheet material (10, 80) intended as the binding edge of a book, by making the weakenings (11): a) without piercing the sheet material (10, 80) and without essentially removing fibers from the sheet material (10, 80) in the hinge area (18), and b) in such a way that at least some of the weakenings (11) remain visible as protrusions and/or feel like protrusions when tested by the finger. In addition, independent patent claims for the device, the printing paper sheet and the book.
