Single Wall Carbon Nanotubes By Atmospheric Chemical Vapor Deposition
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jun 21, 2012
app pub date -
Feb 12, 2008
filing date -
Feb 12, 2008
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
The present disclosure provides for systems and methods for producing carbon nanotubes. More particularly, the present disclosure provides for improved systems and methods for producing single wall carbon nanotubes (SWNTs) by chemical vapor deposition (CVD) using a carbon source in the presence of a catalyst. In exemplary embodiments, the present disclosure provides for improved systems and methods for producing single wall carbon nanotubes (SWNTs) by chemical vapor deposition (CVD) using carbon monoxide (CO) disproportionation in the presence of a catalyst composition on a catalyst support material. In one embodiment, the present disclosure provides for systems and methods for producing single wall carbon nanotubes (SWNTs) by chemical vapor deposition (CVD) using carbon monoxide (CO) disproportionation with CO pressure from about 0.20 atm to about 1.0 atm in the presence of a cobalt/molybdenum catalyst composition on a magnesium oxide catalyst support.
First Claim
Other Claims data not available
