APPARATUS FOR DETERMINING THE THREE DIMENSIONS OF A PARCEL
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
May 10, 2012
app pub date -
Sep 30, 2011
filing date -
Sep 30, 2010
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A method of determining the three dimensions of a parcel, in which method the parcel to be measured is placed against an orthogonal reference support and an image is acquired of said orthogonal reference support having three graduated scales defining the three perpendicular axes of the frame of reference, and a correspondence table is established giving the correspondence between the real distance between each of the graduations of the scales and the corresponding number of pixels of the image, and then an image is acquired of the parcel disposed on the orthogonal reference support, the edges of said parcel are determined along three perpendicular axes, the number of pixels forming each of the edges of the parcel is counted, and a corrector coefficient is applied taken from the correspondence table in order to obtain the looked-for three real dimensions.
First Claim
Other Claims data not available
