SYSTEMS AND METHODS TO IMPROVE ULTRASOUND BEAMFORMING
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Apr 19, 2012
app pub date -
Oct 14, 2011
filing date -
Oct 14, 2010
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
Systems and methods are disclosed to receive a plurality of samples of an ultrasound beam, each of the plurality of samples associated with a tissue depth, determine, for each of a plurality of candidate depths, a difference between the sum of each of the plurality of samples which is associated with a tissue depth from the candidate depth to a predetermined distance below the candidate depth, and the sum of each of the plurality of samples which is associated with a tissue depth from the candidate depth to the predetermined distance above the candidate depth, determine the largest determined difference, and determine the one of the plurality of candidate depths associated with the largest determined difference.
