Automatic Workpiece Edging and Ripping Device and Method
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Oct 20, 2011
app pub date -
Apr 5, 2011
filing date -
Apr 15, 2010
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A sawing apparatus for a wood products sawing system comprises a frame, a sawing table, a workpiece clamping element, and an overhead saw assembly. A workpiece can be supported on the sawing table and releasably secured to the table by the workpiece clamping element. The overhead saw array is supported by the frame and includes a saw driver and a row of at least three saw assemblies so to sever the workpiece along the cut line by movement of the saw blades along two dimensional paths. A variable width sawing table comprises a driving assembly and a row of support arm assemblies mounted to the frame member and coupled to the driving assembly for movement to at least first and second positions.
First Claim
Other Claims data not available
