SHOCK ABSORBING APPARATUS AND METHOD
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Sep 15, 2011
app pub date -
May 18, 2011
filing date -
Aug 1, 2007
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
The present invention in one embodiment is a vacuum pump including a compressible elastomeric member with an internal reservoir enclosing a volume of fluid, an outlet port providing fluid communication between the internal reservoir and a fluid sink, and an inlet port providing fluid communication between the internal reservoir and a fluid source. The pump further includes first and second pressure elements coupled to the elastomeric member on opposing sides. At least one of the first and second pressure elements is adapted to apply a longitudinal force along, and a rotational force about, an axis extending through the compressible elastomeric member. Upon the application of a longitudinal compression force to the compressible elastomeric member, fluid flows from the internal reservoir to the fluid sink and upon the application of a longitudinal expansion force, fluid flows from the fluid source to the internal reservoir. Upon the application of a rotational force, the elastomeric member exerts a counter-rotational force.
First Claim
Other Claims data not available
