Device for removing the ribs from a piece of slaughtered animal
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Aug 11, 2011
app pub date -
May 10, 2005
filing date -
May 11, 2004
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
The invention relates to a device for removing individual ribs from a piece of slaughter animal whose spinal column was cut off. A conveying device aligns the piece on a cutting surface on which the spinal column was cut off and conveys the piece. A rib sensor (1) detects the position if the ribs near the cutting surface. A rib cutting element (8) is advanced to the rib by means of a drive and is displaced along the rib. A control controls the drive of the rib cutting element (8) in accordance with the position detected by the rib sensor (1).
First Claim
Other Claims data not available
