Guide plate for a system for securing a rail on a substrate and a system comprising such guide plate
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Mar 3, 2011
app pub date -
Feb 11, 2009
filing date -
Feb 11, 2009
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A guide plate for securing a rail on a substrate, at which a shoulder is provided at the side of the rail path has an underside facing the substrate and an upper side, lying freely in the installation position and facing away from the underside, on which a spring element is supported. With such a component it is possible to build a rail securing arrangement with a system, in which the forces are dispersed by a shoulder present at or in the solid substrate, whereby a cut-out is formed into the underside, the dimensions of which are adapted to the shoulder such that, in the installation position, the shoulder engages freely into the cut-out, and in that a reinforcement rib is formed at a roof surface opposite an opening of the cut-out, which projects in the direction of the opening over a height which is less than the cut-out.
