Illuminator using non-uniform light sources
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Nov 11, 2010
app pub date -
May 6, 2010
filing date -
May 6, 2009
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
An optical system comprises at least a source module comprising a non-uniform extended source (e.g., RGB-LED), an optical engine, and at least one of a lightpipe and a lenslet array arrangement. The optical engine is by example detailed at co-owned WO 2008/017718, and has a first toroidal ray guide and a second ray guide defining a common axis of revolution and having complementary imaging surfaces and pupils. For the case in which the system includes the lightpipe, such a lightpipe is disposed between the source module and the optical engine. For the case in which the system includes the lenslet array arrangement, the optical engine is disposed between the source module and the lenslet array arrangement. At least one ray guiding component, also detailed at WO 2008/017718, can be an alternative to the above optical engine. The lenslet array arrangement may include first and second lenslet arrays having corresponding lenslets.
