METHOD FOR PRODUCING A HOLDING FRAME OR A TRANSMISSION FRAME FOR A STACKED PIEZOACTUATOR AND ELECTROSTRICTIVE DRIVE WITH A FRAME OF SAID TYPE
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Mar 4, 2010
app pub date -
Nov 7, 2007
filing date -
Nov 20, 2006
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
The invention relates to a method for producing a holding or transmission frame (12, 20) for an electrostrictive actuator, in particular, a stacked piezoactuator (5). Said method consists of the following steps: a) a winding spindle (52), corresponding to the shape of the inner periphery of the frame (12, 20), is wound with several layers of a unidirectional prepreg for forming a laminate body; b) said laminate body is hardened; c) the hardened laminate body in the frame is cut by sections parallel to the direction of winding. An electrostrictive drive (100) comprises an electrostrictive actuator (5) in which the length varies during actuation, and a transmission frame (12) that surrounds the actuator, is connected to said actuator for initiating the variation in length of the actuator and for amplifying said actuator, the transmission frame (12) being made of a prepreg that is wound in the laminate body and hardened.
First Claim
Other Claims data not available
