Clamping device for workpieces with different sizes
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Mar 27, 2012
Grant Date -
Dec 17, 2009
app pub date -
May 19, 2009
filing date -
Jun 12, 2008
priority date (Note) -
Expired
status (Latency Note)
Importance
Abstract
A clamping device for clamping a workpiece includes a support member, sliding members and a rotating member. The support member is configured for supporting the workpiece. The support member defines cutouts in a periphery thereof. The sliding members each is positioned in one of the cutouts. Each of the sliding members has a cam pin. The rotating member is rotatable relative to the support member. The rotating member defines cam slots on top thereof. The cam pins are received in the cam slots and slidable in the cam slots. Positions of the sliding members are changeable along radial directions of the support member when the rotating member is rotated.
First Claim
Other Claims data not available
