Systems And Methods For Halting Locomotion Using Damped Waveform
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
Dec 28, 2007
filing date -
Oct 7, 2003
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
Systems and methods for immobilizing a target such as a human or animal with a stimulus signal coupled to the target via electrodes provide the stimulus signal in accordance with a strike stage, a hold stage, and a rest stage. Systems include a launch device and separate projectile, where the projectile includes a battery, a waveform generator, and electrodes. The strike stage and hold stage may include pulses at a pulse repetition rate, for example, from 10 to 20 pulses per second, each pulse delivering a predetermined amount of charge, for example, about 100 microcoulombs at less than about 500 volts peak. The hold stage may continue immobilization at a lesser expenditure of energy compared to the strike stage. Because the strike stage and hold stage may immobilize by interfering with skeletal muscle control by the target's nervous system, a rest stage may allow the target to take a breath.
First Claim
Other Claims data not available
