Pixel designs for multi-domain vertical alignment liquid crystal display
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Sep 18, 2008
app pub date -
Mar 13, 2007
filing date -
Mar 13, 2007
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
An MVA display includes a plurality of repeats between a first substrate and a second substrate, each of which includes at least one full color pixel, and a drive circuit for driving the plurality of repeats. Each full color pixel includes at least one color dot for each of red, blue and green. Color dots contiguous between at least two adjoining repeats in a row have different colors from each other. Each color dot includes a common electrode, a pixel electrode and a liquid crystal component having a negative dielectric anisotropy between the common electrode and the pixel electrode. The common electrode is common among at least a portion of the repeats. The drive circuit causes color dots contiguous between at least two adjoining repeats in a row to have different polarities from each other.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 3 Citation Count
- G02F Class
- 2.05 % this patent is cited more than
- 17 Age
