Composition and method for making fuel cell collector plates with improved properties
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Aug 3, 2006
app pub date -
Sep 11, 2003
filing date -
Sep 12, 2002
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A method and composition is disclosed for making conductive flow field separator plates having reduced resistivity, lower weight and lower cost. The plates are made by blending from about 0.5 wt % to about 40 wt %, preferably from about 1 wt % to about 30 wt %, most preferably from about 5 wt % to about 20 wt %, of the liquid crystal polymer; from about 0.5 10 wt % to about 40 wt %, preferably from about 1 wt % to about 30 wt %, most preferably from about 5 wt % to about 20 wt % of the poly(styrene-co-maleic anhydride); and from about 20 wt % to about 99 wt %, preferably from about 60 wt % to about 98 wt %, most preferably from about 70 wt % to about 90 wt % of the conductive filler. The blend is then moulded to form the conductive flow field separator plates.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- H01B Class
- 0 % this patent is cited more than
- 19 Age
