Reduction of effects of spurious correlations in ranging receivers
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Aug 12, 2004
app pub date -
Feb 12, 2003
filing date -
Feb 12, 2003
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A position-estimating receiver, that receives ranging signals that are transmitted by multiple sources that modulate the signals with pseudo-random unique to the respective sources, includes data correlation channels, each of which correlates the incoming signals with a replica of the code used by a selected source to acquire the signal from the source in an acquisition mode and tracking the acquired signal in a tracking mode. The receiver detects possible spurious correlations in one or more monitor channels, each of which correlates the incoming signals with the code replica in use by a data channel in the tracking mode, stepping the replica through a succession of code phases other than the phase in the data channel and, if a significant correlation output is detected, causes the data channel to return to the acquisition mode.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2003 Application Filing Year
- H04L Class
- 6496 Applications Filed
- 3150 Patents Issued To-Date
- 48.50 % Issued To-Date
