High chloride emulsion doped with combination of metal complexes

Number of patents in Portfolio can not be more than 2000

United States of America Patent

APP PUB NO 20040033452A1
SERIAL NO

10639537

Stats

ATTORNEY / AGENT: (SPONSORED)

Importance

Loading Importance Indicators... loading....

Abstract

See full text

A radiation-sensitive emulsion comprised of high chloride silver halide grains having a central portion accounting for up to 99 percent of total silver and containing a first dopant of Formula (I): [RuL.sub.6].sup.n wherein n is -2, -3 or -4, and L.sub.6 represents bridging ligands which can be independently selected, provided that at least four of the ligands are anionic ligands, and at least one of the ligands is a cyano ligand or a ligand more electronegative than a cyano ligand; and a second dopant comprising an iridium coordination complex having ligands each of which are more electropositive than a cyano ligand; wherein the first dopant and the second dopants are located together in a common dopant band in an interior shell region of the central portion of the silver halide grains that surrounds at least 70 percent of the silver and, with the more centrally located silver, accounts for 90 percent of the silver halide forming the grains, and wherein the second dopant is present in the silver halide grains in a concentration of at least 10.sup.-7 mole/mole of total silver. The combination of first and second dopants in a common dopant band provides greater reduction in reciprocity law failure than is achieved with such dopants in separate bands, and also provides improvements in speed and contrast properties.

First Claim

See full text

Other Claims data not available

Family

Loading Family data... loading....

Patent Owner(s)

Patent OwnerAddress
EASTMAN KODAK COMPANY343 STATE STREET ROCHESTER NY 14650-0221

International Classification(s)

loading....
  • 2003 Application Filing Year
  • G03C Class
  • 795 Applications Filed
  • 175 Patents Issued To-Date
  • 22.02 % Issued To-Date
Click to zoom InYear of Issuance% of Matters IssuedCumulative IssuancesYearly Issuances2003200420052006200720082009201020112012201320140255075100

Inventor(s)

Inventor Name Address # of filed Patents Total Citations
Eachus, Raymond S Rochester, NY 9 163
Klaus, Roger L Victor, NY 32 106
Lewis, John D Webster, NY 15 55
Mydlarz, Jerzy Z Rochester, NY 23 89
