Liquid feed system
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
Nov 12, 2002
filing date -
Aug 26, 1996
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A liquid feed system supplies liquid from a collapsible container to at least one liquid dispenser. At least one line couples, in fluid communication, the collapsible fluid container to the at least one liquid dispenser. The liquid feed system may include first and second collapsible containers, with the first collapsible container at an elevation higher than the elevation of the second collapsible container. The first and second collapsible containers are coupled, in fluid communication, to one another and to at least one liquid dispenser by at least one connecting line. Other embodiments of the liquid feed system provide for a series connection between the first and second collapsible containers, and the second collapsible container and the at least one dispenser. In these other embodiments, the first and second collapsible containers are coupled, in fluid communication, by a first connecting line, and the second collapsible container and at least one liquid dispenser are coupled, in fluid communication, by a second connecting line.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 17 Citation Count
- G01F Class
- 58.05 % this patent is cited more than
- 22 Age
