Apparatus for meteorological observation
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Oct 17, 2023
Grant Date -
N/A
app pub date -
May 26, 2023
filing date -
Aug 10, 2022
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
In accordance with one aspect of the present disclosure, there is provided an apparatus for meteorological observation, including: a prop; a meteorological sensor, mounted on the prop, configured to measure at least wind direction information; a level configured to maintain a horizon of the prop; a first GPS, mounted on a first area of the prop, configured to acquire first longitudinal information and first latitudinal information; a second GPS, mounted on a second area of the prop, configured to acquire second longitudinal information and second latitudinal information, wherein the second area is separated from the first area by a predetermined distance; a processor configured to calibrate the wind direction information and thus output adjusted wind direction information by referring to a location of the first area, a location of the second area, the first latitudinal information, the first longitudinal information, the second latitudinal information and the second longitudinal information.
First Claim
Other Claims data not available
Family
| Country | kind | publication No. | Filing Date |
|---|---|---|---|
| KR | B1 | KR102504375 | Aug 10, 2022 |
International Classification(s)
- 2023 Application Filing Year
- G01W Class
- 142 Applications Filed
- 48 Patents Issued To-Date
- 33.81 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- G01W Class
- 0 % this patent is cited more than
- 2 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 3.5 Year Payment | $1600.00 | $800.00 | $400.00 | Apr 17, 2027 |
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Apr 17, 2031 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Apr 17, 2035 |
