Support structure
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Nov 8, 2022
Grant Date -
Jun 3, 2021
app pub date -
Nov 20, 2020
filing date -
Nov 29, 2019
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A support structure includes: a support frame as a shaft support member for supporting two shafts; a bush provided on each of the two shafts in a slidable manner; a cover support member connected to the multiple bushes and configured to support the cover; a first connection member for connecting one end of each of the two shafts to the support frame in a manner that the relative position between the shaft and the support frame will not change; and a second connection member for connecting the other end of each of the two shafts to the support frame in a manner that the relative position between the shaft and the support frame can change.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2020 Application Filing Year
- B23Q Class
- 667 Applications Filed
- 360 Patents Issued To-Date
- 53.98 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B23Q Class
- 0 % this patent is cited more than
- 3 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 3.5 Year Payment | $1600.00 | $800.00 | $400.00 | May 8, 2026 |
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | May 8, 2030 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | May 8, 2034 |
