Gangway for connecting a first car of a multi-car vehicle to a second car
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Oct 25, 2022
Grant Date -
Feb 4, 2021
app pub date -
Aug 3, 2020
filing date -
Aug 2, 2019
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A gangway for connecting a first car of a multi-car vehicle to a second car, comprising a first vehicle mounting plate at a first end for mounting the gangway to the first car, a second vehicle mounting plate at a second end for mounting the gangway to the second car or to a frame arranged at the second end for mounting the gangway to a second gangway, a first frame arranged between the first vehicle mounting plate and second vehicle mounting plate, or between the first vehicle mounting plate and a frame arranged at the second end for mounting to a second gangway, a second frame between the first vehicle mounting plate and first frame, wherein a bellows is attached to at least one of the first and second frames, first vehicle mounting plate and second vehicle mounting plate or the frame arranged at the second end.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2020 Application Filing Year
- B61D Class
- 151 Applications Filed
- 86 Patents Issued To-Date
- 56.96 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B61D Class
- 0 % this patent is cited more than
- 3 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 3.5 Year Payment | $1600.00 | $800.00 | $400.00 | Apr 25, 2026 |
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Apr 25, 2030 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Apr 25, 2034 |
