UV pattern forming method using inkjet printing, bezel manufacturing method including same, and bezel manufactured according thereto
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Sep 20, 2022
Grant Date -
N/A
app pub date -
Aug 28, 2017
filing date -
Dec 9, 2016
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A method for forming a UV pattern using inkjet printing, which enables to form a hairline or pattern having metallic luster in a single inkjet patterning process, a method for manufacturing a bezel comprising the same, and a bezel manufactured thereby are disclosed. The method for forming a UV pattern using inkjet printing comprises the steps of a) inkjet printing an ultraviolet curable ink containing metal particles in a non-display area of a cover window for a display to form a UV pattern; and b) curing the UV pattern. The bezel can be used in various fields such as a touch panel, a protective film for an optical disc, and the like.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2017 Application Filing Year
- B41M Class
- 639 Applications Filed
- 440 Patents Issued To-Date
- 68.86 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B41M Class
- 0 % this patent is cited more than
- 3 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 3.5 Year Payment | $1600.00 | $800.00 | $400.00 | Mar 20, 2026 |
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Mar 20, 2030 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Mar 20, 2034 |
