Bicycle and tire structure
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Aug 23, 2022
Grant Date -
Jul 18, 2019
app pub date -
Jan 9, 2019
filing date -
Jan 12, 2018
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A tire structure disposed at a rim is provided. The tire structure includes a tire body, a flexible sealing member and a nozzle. The tire body is ring-shaped and includes a groove and two beads. The flexible sealing member is connected to the tire body to form an inflating space with the groove, and the flexible sealing member includes a through hole. The nozzle is disposed at the flexible sealing member. The nozzle includes a base and a valve stem. The base includes a screw hole and is disposed at a far side of the flexible sealing member. The screw hole corresponds to the through hole. The valve stem includes a fastening end and an inflating channel. The fastening end is configured to insert into the screw hole, and the inflating channel is configured to allow the gas to pass therethrough.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2019 Application Filing Year
- B60C Class
- 1171 Applications Filed
- 654 Patents Issued To-Date
- 55.85 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B60C Class
- 0 % this patent is cited more than
- 3 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 3.5 Year Payment | $1600.00 | $800.00 | $400.00 | Feb 23, 2026 |
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Feb 23, 2030 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Feb 23, 2034 |
