Transition between a waveguide and a substrate integrated waveguide, where the transition includes a main body formed by symmetrical halves
Number of patents in Portfolio can not be more than 2000
United States of America
Stats
-
Mar 1, 2022
Grant Date -
Aug 26, 2021
app pub date -
Feb 21, 2020
filing date -
Feb 21, 2020
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A broadband transition coupling for transition between a waveguide and a printed circuit board with a substrate integrated waveguide is disclosed. The broadband transition coupling comprises a main body that encompasses an air-filled waveguide section and a transition section. The air-filled waveguide section comprises a first interface for the waveguide. The transition section provides a second interface for the printed circuit board. The transition section continuously tapers along the second interface in order to reduce a height of the transition section for transition coupling with the printed circuit board. Further, the present disclosure relates to a broadband system for processing electromagnetic signals.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2020 Application Filing Year
- H01P Class
- 633 Applications Filed
- 471 Patents Issued To-Date
- 74.41 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- H01P Class
- 0 % this patent is cited more than
- 3 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 3.5 Year Payment | $1600.00 | $800.00 | $400.00 | Sep 1, 2025 |
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Sep 1, 2029 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Sep 1, 2033 |
