Screen printing apparatus, screen printing method, and electrode formation method of solar battery
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Aug 24, 2021
Grant Date -
Aug 2, 2018
app pub date -
Jul 15, 2016
filing date -
Jul 22, 2015
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A method for screen printing, including: by using a screen printing apparatus provided with a screen printing plate having an opening part corresponding to a printing pattern, a scraper, and a squeegee, filling a paste supplied on an upper surface of the screen printing plate into the opening part of the screen printing plate by the scraper; and, after that, pushing out the paste to a predetermined position of an object to be printed from the opening part of the screen printing plate by the squeegee to screen-print the paste corresponding to the printing pattern on the object to be printed, wherein the humidity in the screen printing apparatus is adjusted during the screen printing. As a result, by controlling an amount of moisture in the paste on the screen printing plate, a screen printing method is capable of improving the printing property of the paste.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2016 Application Filing Year
- B41M Class
- 602 Applications Filed
- 439 Patents Issued To-Date
- 72.93 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B41M Class
- 0 % this patent is cited more than
- 4 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 3.5 Year Payment | $1600.00 | $800.00 | $400.00 | Feb 24, 2025 |
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Feb 24, 2029 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Feb 24, 2033 |
