Method using bismuth based alloy as power-off element
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Mar 2, 2021
Grant Date -
N/A
app pub date -
Nov 27, 2018
filing date -
Jul 3, 2018
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
The present invention discloses a method using a bismuth based alloy as power-off element, comprising: a bismuth based alloy is used as the power-off element and a melting point of the bismuth based alloy is between 100° C. to 380° C.; when the power-off element is in an environment below the melting point, two conductive elements are mutually contacted and capable of conducting currents, whereas the power-off element is only receptive of the currents but does not serve as a medium for conducting the currents; when a working temperature of a switch or the socket is close to or exceeds the melting point, the power-off element loses rigidity and enables the two conductive elements to be separated from each other, thereby forming an electrically disconnected state.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- H01R Class
- 48.10 % this patent is cited more than
- 4 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Sep 2, 2028 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Sep 2, 2032 |
