Three-dimensional filaments-linked structure manufacturing apparatus, manufacturing method of three-dimensional filaments-linked structure, and mattress core material
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Sep 8, 2020
Grant Date -
May 31, 2018
app pub date -
May 26, 2016
filing date -
Jan 13, 2016
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A manufacturing apparatus and manufacturing method for manufacturing a three-dimensional filaments-linked structure includes: divided weight information acquisition means which records divided weight information acquired by dividing weight distribution in a height direction of a person in a height axis direction, in correlation with a distance from a top of a head of the person; and three-dimensional linked structure formation means which tangles and fuses filaments of a thermoplastic resin material extruded from an extruder in a three-dimensional net shape, and forms a three-dimensional filaments-linked structure which is long in a product streaming direction, and the three-dimensional linked structure formation means includes filament density control means which controls filament density in the product streaming direction based on the divided weight information. As a result of the configuration, it is possible to promptly, reliably, and efficiently manufacture products with desired specifications for customers who request products with made-to-order specifications.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2016 Application Filing Year
- A47C Class
- 1122 Applications Filed
- 792 Patents Issued To-Date
- 70.59 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- A47C Class
- 0 % this patent is cited more than
- 5 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Mar 8, 2028 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Mar 8, 2032 |
