Ice cube maker
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Aug 20, 2019
Grant Date -
May 12, 2016
app pub date -
May 13, 2014
filing date -
May 28, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
An apparatus for making ice cubes includes a plurality of elongated elements (1, 2). A plurality of mold parts (3, 4, 5, 6) are movable with respect to the elongated elements (1, 2). The plurality of mold parts are movable to form a mold (7) around a first elongated element (1) of the elongated elements. A control unit is configured to control a movement of the plurality of mold parts with respect to the elongated elements to move the mold parts (3, 5) forming the mold (7) around the first elongated element (1) apart once a first ice column (201) has been formed in the mold (7), and form a mold (8) around a second elongated element (2) of the elongated elements. An ice remover (202) is configured to remove the first ice column (201).
First Claim
Other Claims data not available
Family
International Classification(s)
- 2014 Application Filing Year
- F25C Class
- 99 Applications Filed
- 78 Patents Issued To-Date
- 78.79 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- F25C Class
- 0 % this patent is cited more than
- 6 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Feb 20, 2027 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Feb 20, 2031 |
