Coil component
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Nov 20, 2018
Grant Date -
Oct 12, 2017
app pub date -
Mar 7, 2017
filing date -
Apr 6, 2016
priority date (Note) -
In Force
status (Latency Note)
Importance
Calculated Rating
|
US Family Size
|
Non-US Coverage
|
Abstract
A coil component including: a magnetic core that contains an Fe-based magnetic powder and a binding agent, the Fe-based magnetic powder having an insulator film and having a volume resistivity of 107 Ω·cm or more; and a coil conductor. The average particle size D50 of the Fe-based magnetic powder is 5 μm or smaller and the magnetic permeability of the magnetic core is 5 or more.
First Claim
Other Claims data not available
Family
+
−
| Country | kind | publication No. | Filing Date |
|---|---|---|---|
| JP | B2 | JP6613998 | Apr 06, 2016 |
| TW | B | TWI637408 | Jan 13, 2017 |
| CN | B | CN107275057 | Feb 10, 2017 |
International Classification(s)
- C03C:CHEMICAL COMPOSITION OF GLASSES, GLAZES, OR VITREO....
- B22F:WORKING METALLIC POWDER; MANUFACTURE OF ARTICLES F....
- H01F:MAGNETS; INDUCTANCES; TRANSFORMERS; SELECTION OF M....
- B32B:LAYERED PRODUCTS, i.e. PRODUCTS BUILT-UP OF STRATA....
- C08K:USE OF INORGANIC OR NON-MACROMOLECULAR ORGANIC SUB....
- C22C:ALLOYS
- 2017 Application Filing Year
- C03C Class
- 1122 Applications Filed
- 751 Patents Issued To-Date
- 66.94 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- C03C Class
- 0 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | May 20, 2026 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | May 20, 2030 |
